Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration

Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration
Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration

Large Image :  Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration

Product Details:
Place of Origin: CHINA
Brand Name: SINOCOREDRILL
Certification: ISO9001
Model Number: BW NW HW HWT PW
Payment & Shipping Terms:
Minimum Order Quantity: N/M
Price: BASED ON DETAILED ORDER
Packaging Details: STANDARD EXPORT
Delivery Time: 1 WEEK
Payment Terms: L/C, T/T
Supply Ability: 1000/MONTH

Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration

Description
TYPE: Tungsten Carbide TC Casing Shoe Bit Material: Tungsten Carbide
Size: BW NW HW HWT PW NW OD: 91.82MM
NW ID: 76MM Standard: DCDMA
HS CODE: 820719 Color: Black
APPLICATION: Mineral Exploration
High Light:

TC Drilling Casing Shoe Bit

,

High Penetration Casing Shoe Bit

,

Tungsten Carbide TC Casing Shoe Bit

High Penetration Open Hole Casing Shoe NW Tungsten Carbide TC Casing Shoe Bit





Casing Shoes are diamond tools used to avoid material to collapse into the hole. Normally casing shoers are screwed on casing rods, used in mining or geotechnical and geothermal applications.



Casing shoe is used on the leading edge of a casing tube string to advance it through the overburden layer and into the bedrock by means of rotational drilling. Depending on the range of application, the cutting media on the core bit may take the form of synthetic diamond, tungsten-carbide particles or tungsten-carbide elements.





Casing shoes for drilling have cutting segments on the front and exterior, while the interior is smooth. The inner diameter of the casing shoe is sufficiently large to permit free passage of drill bits and core barrels in corresponding sizes.




Specification :



Type

Description

DOI (mm)

Waterways (mm)

BW  Casing Shoe Bit 6 6 x 3
HW  Casing Shoe Bit 6 10 x 5
HWT  Casing Shoe Bit 6 10 x 5
NW  Casing Shoe Bit 6 6 x 4
PW Gold Casing Shoe Bit 6 12 x 5





Casing Shoe Sizes
DESCRIPTION Outer Diameter Inner Diameter
Inch mm Inch mm
AW 2.345 59.56 1.9 48.26
B/WL 2.965 75.31 2.37 60.2
N/WL 3.615 91.82 2.992 76
H/WL 4.625 117.48 3.925 99.7
HWT 4.625 117.48 3.925 99.7
P/WL 5.653 143.58 4.855 123.3
T2-56 2.205 56 1.85 47
T2-76 2.992 76 2.638 67
T2-86 3.385 86 2.823 71.7
T2-101 3.976 101 3.031 77
T6-101 3.976 101 3.445 87.5
T6-131 5.157 131 4.646 118
Size Outside Set Diameter Inside Set Diameter
Inch mm inch mm
AW* 2.350 / 2.340 59.69 / 59.44 1.902 / 1.897 48.31 / 48.18
BW 2.970 / 2.960 75.44 / 75.19 2.377 / 2.367 60.38 / 60.12
NW* 3.620 / 3.610 91.95 / 91.70 2.997 / 2.987 76.12 / 75.87
HW* 4.632 / 4.617 117.65 / 117.27 3.980 / 3.970 101.09 / 100.84
HWT 4.632 / 4.617 117.65 / 117.27 3.930 / 3.920 99.82 / 99.57
PW** 5.660 / 5.640 143.76 / 143.26 4.865 / 4.850 123.57 / 123.19
PWT 5.660 / 5.640 143.76 / 143.26 4.865 / 4.850 123.57 / 123.19
SW* 6.800 / 6.780 172.72 / 172.21 5.948 / 5.933 151.08 / 150.70

Size Unit weight (kg)
AW 0.5
BW 0.9
NW 1.6
HW 2.3
PW

3.2





Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration 0

Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration 1

Tungsten Carbide Open Hole NW TC Drilling Casing Shoe Bit High Penetration 2
