Product Details:
|
| Features: | High Precision, High Hardness, Corrosion Resistant | Product Name: | Drill Pipe Casing |
|---|---|---|---|
| Material: | Alloy Steel | Usage: | Well Drilling, Drill Deep Hole |
| Technique: | Cold Rolled | Type: | Wireline Drill Inner Tube |
| High Light: | steel casing pipe,well drilling pipe |
||
High Performance Cold Rolled Drill Pipe Casing NQ HQ PQ Wireline Drill Tube
Description:
We produce a wide range of drilling tool including drill rod, wireline core barrel (AQ-PQ) and assemblies, synthetic diamond core bits, natural diamond surface-set core bit, PDC bits (core or noncoring), casing shoes, reaming shells, overshot, hoisting plug, water swiel, wrench.
These are all manufactured to the strictest quality standards as British / Swedish / DCDMA / CDDA / Metric standards, and used around the world in a great variety of applications.
We are the member of the National Drilling Association (NDA). We are committed in carrying out advanced technological research, and providing customers with products of outstanding quality and satisfied service.
NQ HQ PQ Wireline drill Inner tube
1 alloied material split inne tube
2 thru-wall heat treated tube body
3 ISO control process
4 Cold rolled
Size Available:
"Q" Series: BQ, NQ, HQ, and PQ.
"WJ" Design: AWJ, BWJ, NWJ, KWJ, HWJ
"W" Design: RW, EW, AW, BW, NW, HW
Metric Series: 33, 42, 50
We also can produce various sizes of casing tubes
Size Available:
"W" Design: RW,EW,AW,BW,NW,HW,PW,SW,UW,ZW/HWT,PWT
Metric Series: 46, 56,66,76,86,101,116,131,146
"X" Design: RX, EX, AX, BX, NX, HX, PX, SX, UX, ZX
All Chinese sizes.
|
Decription |
OD(mm) |
ID(mm) |
Weight(Kg/3m) |
|
Rod, BQ 3.0 m Enhanced |
Φ55.60 |
Φ46 |
18.00 |
|
Rod, NQ 3.0 m Enhanced |
Φ70.15 |
Φ60 |
23.40 |
|
Rod, HQ 3.0 m Enhanced |
Φ89 |
Φ77.80 |
35.50 |
