10 Feet NRQ HRQ Wireline Drill Rod Consistent Concentricity For Rock Exploration

Product Details:

Place of Origin:	CHINA
Brand Name:	SINOCOREDRILL
Certification:	CE , ISO9001
Model Number:	BRQ NRQ HRQ

Payment & Shipping Terms:

Minimum Order Quantity:	N/A
Price:	Negotiable
Packaging Details:	Sea Delivery Package
Delivery Time:	1 week
Payment Terms:	T/T
Supply Ability:	1000/month

Contact Now

Detailed Product Description

Type:	DRILLING ROD	Material:	30CrMnSia XJY850
SIZE:	BRQ NRQ HRQ	Length:	3m 1.5m
Standard:	DCDMA	Country:	China
HS Code:	730451
Highlight:	HRQ Wireline Drill Rod , NRQ Wireline Drill Rod , 10 Feet wireline drill rod

Consistent Concentricity 10 Feet High Quality China Made BRq NRq HRq Wreiline Drill Rod For Rock Exploration

Rq series wireline drill rods follow international industry standard. RQ series drill rods feature exclusive heat treatment and course RC thread. Rq rods expand drilling capacity in deep, deviated and demanding wireling coring application.

Rq drill rods expand your drilling capabilities and lower your total drill rod cost per meter/foot in deep, deviated, and demanding wireline coring applications.

Our drill rods are all manufactured by CNC machines. They're made of high quality alloy steel. All our drill rods are complete heat-treated.

Our rods will be also suited to drill deep holes. From drillers' feedback, our rods have drilled up to 2000 meters depth.

HRQ wireline drill rod heat treatment

●Provides higher material strength

●Whole rod Heat treated significantly increases rod life

HRQ wireline drill rod overview

Rod Model	OD (mm)	ID (mm)	Threads Pitch(mm)	Pin Length(mm)	Rod Length(m)	Packing Dimension (mm)	Gross Weight (KG)	Unit Bundle Qty (pcs)
BQ	55.6	46.1	8.5	44.5	3	3150292254	283	19
NQ	69.9	60.3	8.5	44.45	3	3124368330	453	19
HQ	88.9	77.8	8.5	44.45	3	3048470406.4	682	19
PQ	114	102	10.2	63	3	3200368330	373	7
BRq	55.6	46.1	8.5	42	3	3150292254	357	19
NRq	69.6	60.3	8.5	42	3	3124368330	453	19
HRq	88.9	77.8	8.5	42	3	3200470406.4	682	19
PHD	114	102	10.2	63	3	3200368330	373	7

10 Feet NRQ HRQ Wireline Drill Rod Consistent Concentricity For Rock Exploration 2

10 Feet NRQ HRQ Wireline Drill Rod Consistent Concentricity For Rock Exploration 3

10 Feet NRQ HRQ Wireline Drill Rod Consistent Concentricity For Rock Exploration 4
