Name: Drill Pipe Casing For Mining , Flush-jointed Water Well Casings 4" - 8 "
Brand: Jiangsu Sinocoredrill Exploration Equipment Co., Ltd
Price: 99.00 USD
Availability: InStock

Home Products Wireline Drill Rod

Drill Pipe Casing For Mining , Flush-jointed Water Well Casings 4" - 8 "

Product Details:

Place of Origin:	CHINA
Brand Name:	SINOCOREDRILL
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	N/A
Packaging Details:	Sea Delivery Package
Delivery Time:	Based on Detailed Order
Payment Terms:	T/T
Supply Ability:	Based on Detailed Order

Contact Now

Detailed Product Description

Features:	High Precision, High Hardness, Corrosion Resistant	Product Name:	Drill Pipe Casing
Material:	Alloy Steel	Usage:	Well Drilling, Drill Deep Hole
Technique:	Cold Rolled	Type:	Drill Rod/ Casing Pipe/ Drill Pipe
Highlight:	steel casing pipe , well drilling pipe

Drill Pipe Casing For Mining , Flush-jointed Water Well Casings 4" - 8 "

Specifications

Drill Rod/ Casing Pipe/ Drill Pipe
1. AW, BW, RW, NW, HW, PW etc
2. Long use life, low price
3. Manufacturer, ISO approve

Application:

Mainly used for gas drainage hole, also widely used for mining, geology exploration, hydroeceltric dam.

Technical Parameters

Size	OD (mm)	ID (mm)
WLA	44.7	37.3
WLB	55.7	46.1
WLN	70.0	60.2
WLH	89.0	78.0
WLP (PHD)	114.5	101.5
AW/ AWJ/AWY	43.7	30.7
BW/ BWJ/ BWY	54.0	38.0
NW/ NWY	66.8	51.0
HW	89.0	71.0
42	42.0	30.0
50	50.0	37.0
60	60.0	48.0
70	73.0	54.6
90	89.0	69.0
S75	71.0	61.

3. Size Available/ Diameter:

Casing pipe Metric Series Casing size:

SIZE	O.D.(mm)	I.D.(mm)
46	44.15	37.15
56	54.15	47.15
66	64.25	57.25
76	74.25	67.25
86	84.25	77.25
101	98.00	88.30
116	113.00	103.30
131	128.00	118.30
146	143.00	133.30

4. Flush-jointed W series Casing size:

Size	OD		ID
Size	Inch	mm	Inch	mm
BW	2.874	73.0	2.374	60.3
NW	3.500	88.9	3.000	76.2
HW	4.500	114.3	4.000	101.5
PW	5.500	139.7	5.000	127.0

5. Flush-Coupled X Series Casings

Size	OD		ID
Size	Inch	mm	Inch	mm
NX	3.500	88.9	3.000	76.2
HX	4.500	114.3	3.937	100.0
PX	5.500	139.7	4.867	123.6

6. Flush-jointed Water Well Casings (B.S.879)

Size	OD		ID
Size	Inch	mm	Inch	mm
4"	4 1/2"	114.3	3 7/8"	98.3
5"	5 1/2"	139.7	4 7/8"	123.7
6"	6 5/8"	168.3	5 7/8"	149.3
8"	8 5/8"	193.7	7 7/8"	174.7
