High Heat Resistant Impregnated Diamond Core Bit for Deep Geological Drilling up to 800m BQ NQ HQ PQ

Detail Information

Product Description

Detail Information

Highlight:

high heat resistant diamond core bit

deep geological drilling diamond core bit

800m BQ NQ HQ PQ diamond core bit

Product Description

High Heat Resistant Impregnated Diamond Core Bit

Engineered for deep geological drilling operations where extreme temperatures challenge conventional bits, our High Heat Resistant Impregnated Diamond Core Bit delivers unmatched thermal stability and consistent cutting performance at depths exceeding 800 meters.

Key Features

Special heat-resistant metal bond matrix maintains diamond exposure at up to 600°C operating temperature
Optimized diamond concentration and distribution for sustained cutting efficiency in high-temperature environments
Face discharge design ensures efficient debris removal and cooling under deep hole conditions
Available in BQ (59.5mm), NQ (75.3mm), HQ (95.6mm), and PQ (122.2mm) standard sizes
Suitable for BST 7/9 to BST 14 hardness range covering medium-hard to ultra-hard formations

Applications

Deep mineral exploration drilling beyond 800m
Geothermal energy resource exploration
Ultra-deep mining core sampling programs
High-temperature geological surveys

Technical Specifications

Parameter	Specification
Matrix Type	High-temperature resistant alloy bond
Max Operating Temperature	600°C
Diamond Type	Synthetic industrial diamond
Crown Profile	Face discharge turbo
Thread Connection	API standard wireline
Hardness Range	BST 7/9 to BST 14
