NW HW HWT Wireline Casing Pipe , Super Core Drilling Casing Tube 3m 1.5m
N/A
MOQ
NW HW HWT Wireline Casing Pipe , Super Core Drilling Casing Tube 3m 1.5m
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: SINOCOREDRILL
Certification: CE
Model Number: BW NW HW PW HWT
High Light:

drill extension rod

,

oil hardening drill rod

Payment & Shipping Terms
Packaging Details: Sea Delivery Package
Delivery Time: Based on Detailed Order
Payment Terms: T/T
Supply Ability: Based on Detailed Order
Specifications
Type: Casing Tube
Length: 3m 1.5m
Standard: DCDMA
Size: BW NW HW HWT PW
Product Description







NW HW HWT Wireline Casing Pipe Core Drilling Casing Tube 3m 1.5m



1.Our NW HW PW casing tubes are of the highest quality ,are manufactured to exacting specifications using advancing maching technoogy.


2. They are manufactured from seamless steel tube by cold drawn.The material is XJY850/30CrMnSiA which meets the global standard.


3. Drill rods are made from quality heat treated materials which ensure superior strength, wear resistance and toughness in the most demanding applications


4. Rods and casing are manufactured under stringent industry standards, and are field tested under a variety of conditions.


5. All rods are designed to be compatible with other rods manufactured to the standard DCDMA





W Casing Numbers
Std OD (mm) ID (mm) Wall Thickness
(mm)
Thread Pitch
(mm)
Pin Thread Length
(mm)
Weight
(kg/m)
AW 57.20 48.40 4.40 6.35 57.20 5.73
BW 73.00 61.00 6.00 6.35 63.50 10.51
NW 88.90 76.20 6.35 6.35 69.90 12.92
NWA 91.00 80.00 5.50 6.00 72.00 11.59
HW 114.30 101.60 6.35 6.35 76.20 16.90
PW 139.70 127.00 6.35 8.47 82.60 20.87





WT Casing Numbers
Std OD (mm) ID (mm) Wall Thickness
(mm)
Thread Pitch
(mm)
Pin Thread Length
(mm)
Weight
(kg/m)
HWT 114.30 101.60 6.35 10.16 62.74 16.90
PWT 139.70 127.00 6.35 10.16 62.74 20.87
