Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis

Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis
Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis

Large Image :  Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis

Product Details:
Place of Origin: CHINA
Brand Name: SINOCOREDRILL
Certification: ISO9001
Model Number: EP200
Payment & Shipping Terms:
Minimum Order Quantity: N/M
Packaging Details: 1*20GP container
Delivery Time: 30 DAYS

Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis

Description
Dill Depth Capacity: 30/100/200m Hole Diameter: 96/75.7/60mm HTW NTW BTW
Core Diameter: 63.5/56/42mm Engine Power: KUBOTA 23.5kw/3000rpm
Hydraulic System: 21MPa/max 54L/min Water Cooler Maximum Toque: 400NM
Drill Angle: 45°-90° Platform Area/Module Quantity: 2.5m X2.5 M / 4PCS
Heaviest Module/Gross: 176kg / 513kg Type: Full Hydraulic Core Drill Rig
High Light:

200m portable core drill rig

,

200m hydraulic drilling rig

,

alloy chassis portable core drill rig

BTW 200M Portable Core Fully-Hydraulic Aluminum Alloy Chassis Drilling Rig





Both light and efficient, EP200 is a portable fully-hydraulic drill rig. It can drill up to 200 meters with
the capability to add on more for deeper drilling.

Various module combinations available for drilling rigs' different requirements:

1. Aluminum alloy chassis

2. The whole chassis drill rig

3. Crawler self-propelled drill rig

4. Vehicle-mounted drill rig

5. Asynchronous motor module

6. EP200 series horizontal drilling frame module





Features of EP series portable fully-hydraulic drillig rig:





1. Modularized with mast drilling frame

• Lightweight design with the heaviest module weighting less than 180Kg, manpower and does not require road construction;

• Mast drilling frame that can be easily transported and disassembled; does not require drilling derricks;

• Top-drive power heads; long-way guide rail; push by oil cylinders; does not require repeated rechucks;good orientation;

• Operated in small area; does not require foundation construction and environmentally-friendly.

2. Fully hydraulic transmission

• Flexible and lightweight design for easy operation and maintenance;

• Steady drilling with adjustable and high speed;

• Real-time over-pressure protection provided.

3.Thin-wall wireline coring technical

• The drilling pole system with well controlled borehole inclination;

• Thin-wall drill bit with small torque resistance, high cutting speed and drilling rate;

• Large coring diameter and high coring rate;

• Small annulus to reduce accidents and improve safety.







Application Fields





They are widely used for Geological Mineral Exploration, Infrastructure Construction Investigation, Water Conservancy and Hydropower Investigation,Railway/Highway/Bridge/Tunnel Investigation, Advanced Geological Forecast Drilling, Pile Validation and Core-drawing Investigation.



Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis 0

Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis 1

Btw 200m Portable Core Drill Rig Fully Hydraulic Aluminum Alloy Chassis 2





Parameters

Technical Parameter
Drill pipe type HTW/NTW/BTW Winch
Drill pipe length 1.0m Average speed 150m/min
Drill depth capacity 50/100/200m Pulling force 600kg
Hole diameter 96/75.7 /60mm Wire rope diameter 5mm
Core diameter 71/56/42mm Rope capacity 340m
Hydraulic System Mud Pump
Engine power KUBOTA Turbo-charged engines
1×23.5kw/3000rpm
Max. flowrate 75L/min
Max. pressure 21MPa Max. pressure 7MPa
Max. flowrate 66L/min Gripper
Top Drive Rotation Head Capacity 114/HTW/NTW/BTW
Drilling angel 45°- 90°& 0°- 90° matching bracket
Max. torque 400N·M Platform area 3mx3m×3.8m
Rotation speed 1100rpm Module quantity 6PCS
Feed travel 1.27m Heaviest module 176kg
Pull/Thrust 33KN/24KN (double cylinder force doubled) Gross

513kg
